Weight :7000 kg
ODM/OEM :Available
Length, Width, Height :7150mm * 2650mm * 3000mm
Self Loading Mixer for Construction Projects
The Self Loading Mixer boasts an impressive discharge port height of 1.65 meters, enabling seamless and effortless operation. With a horizontal rotation capability of 270 degrees, the tank is thoughtfully engineered to be easily raised and lowered. The self concrete mixer designed to elevate your work productivity and efficiency.
Self Loading Mixer Features
1. Equipped with manganese steel frame, widen luxury cab, cement bucket. Two 150 cm detachable chute to increase discharge length. With a horizontal rotation capability of 270 degrees.
2. Featured with the automatic water measurement, guarantees precise water dosing, ensuring optimal concrete mixing quality.
3. Equipped with an advanced hydraulic system, the self loading mixer enables swift self-loading of aggregates, cement, and water with ease, eliminating the need for additional equipment or labor
1. With a driving video, you'll have complete visibility of your surroundings, eliminating blind spots and enhancing safety during operation.
2. The LED lighting fixtures provide exceptional visibility even in low-light conditions, ensuring optimal performance at all times.
3. Equipped with a roof-mounted work warning light, providing a visual signal to alert nearby workers or pedestrians of its presence. This feature is especially crucial when operating in busy construction sites or crowded areas.
This self concrete mixer can cater to a wide range of construction needs, ensuring convenience and flexibility on the job site.
Wheel loaders are capable of moving the material from point A to B on their own, but they also synergize with other common construction machines. Ever see a dump truck full of rocks and wonder how they got them in the dump truck in the first place? It is not called a pickup truck, after all.
Wheel loaders work to scoop objects and put them into the dump truck, which can then travel faster and further than a wheel loader can, which is great for when the final location for the material is different from the initial lot.
In some cases, a wheel loader might have its own storage compartment. The most notable example of this is a garbage truck, scooping trash to put into itself to deliver elsewhere.
Simplified Maintenance
With long service intervals and quality components, maintaining the machine is easy
The engine air filter has been relocated to the rear of the engine compartment, providing easier access at ground level for maintenance. The urea tank is also positioned for convenience
For safer and easier maintenance, the battery disconnect switch is now included as standard. This helps to avoid electrical accidents and retain battery energy during long-term storage
Equipped with one battery compartment instead of two, which provides easier access for maintenance and battery replacement. This results in minimal downtime and a high level of availability
Self Loading Mixer Technical Parameters
| Model | NST26 |
| Output per lot | 2.6cubic metres |
| Drum rotation | discharge port height 1.65 M, horizontal rotation 270 degrees, tank can be raised and lowered |
| Capacity | Up to 4 batches per hour, 10.4cubic hours |
| Engin | Yuchai 4102 supercharged, diesel, water cooled, 4 cylinder, 2200 rpm |
| Climb | 40 degrees |
| Speed | dual altitude, low speed 0-25 kph, high speed 0-40 kph |
| Driver's seat | Widen luxurious cab, anti-rollover, anti-falling object type |
| Hydraulic system | Open type oil, two gear pumps to participate in the work |
| Joystick | Two hydraulic pilot joysticks control the scoop, upper arm, 270 turn, lift tank |
| Bucket | 0.6 cubic, hydraulic gate |
| Water Supply System | self-priming driven pump, 24V self-timing Centrifugal pump, 24V car wash machine |
| Brake | Use Small Servo pump on independent double circuit, use single wheel 4-piston plus double brake caliper |
| Steering | Hydraulic articulated steering |
| Tyres | 12R22.5 steel wire tyres |
| Power System | 24V |
| Fuel tank / Water tank | 1 * 600 l water tank, 120 l diesel fuel tank, 120 l hydraulic fuel tank |
| Weight | 7000 kg |
| Length, width, height / wheelbase / Wheelbase | 7150mm * 2650mm * 3000mm * 2900mm * 2100mm |
| Turning radius | 2800 mm |
With technological innovation, our product configuration and parameters will
continue to change without notice;
Detailed and application picture of the self-loading mixer
