- Model:
FD30K
- Load capacity:
3000KG
- Lift Height:
3000-6000mm
- Fork Length:
1070-2000mm
- Load center::
500mm
- Engine:
XINCHAI/ISUZU/MITSUBISHI
Our production and equipment
5
years
We have been working in the industry
4
certificates
We have obtained most of the professional certificates in the industry and insist on international standards of production.
3
awards
We have won a lot of awards for strong creativity
NUO SHINGTON(HANGZHOU) PRECISION MACHINERY LTD is one of the most experienced manufacturers and suppliers of manufacturer specializing in the production of handling equipment in China.
We have internal combustion counterbalanced forklifts, battery counterbalanced forklifts, electric logistics handling equipment container cranes, electric hoists, etc.,
Welcome to buy high quality customized products made in China here from our factory. For quotation and free sample, conatct us now.
Our electric counterbalance forklift is designed for maximum efficiency and operator comfort. Its hydraulic, braking, acceleration, and ESC systems are electronically controlled, reducing labor intensity while improving safety and precision. For narrow warehouse environments, forklift also provides the Aisle Master electric forklift, engineered to maximize space utilization and productivity in tight aisles.
Nuo Shington
Product display
Nuo Shington
Product advantages
Classic exterior design ,rugged frame and large, the clear frontand rear views provide operators with excellent visibility,ensuring safety at all times.
The well-designed cab offers more legroom, while the joystickis side-positioned for easier handling. The wide brake pedalallows braking from multiple foot positions, helping to reducefatigue.
Intelligent electronic monitoring instrument, with high reliability.electrical system using waterproof sealing plug-in structure,improve safety and reliability.
High-quality transmission components are matched with thehydraulic system to make the vehicle more efficient and energyefficient.
Standard Equipment >>>
1. Hour meter 2.Oil pressure alarm 3.Hydraulic filter 4.Lamp guard 5.Charge director 6.Back-up buzzer 7.Hydraulic steering 8.Standard fork 9.Drawbar pin 10.Horn 11.Back-up alarm 12.Rear working light 13.2-stage mast 14.Awning 15.Standard seat
Option >>>
1. Cabin 2. High exhaust 3.Suspend seat 4. Fork extension 5.Solid tire 6.Windshild 7. Heater 8. Wider fork carriage 9.Anti-fire muffer 10.Customer color 11.Lifting hook 12.Carpet probe 13.Sider shifter
Nuo Shington
About us
logistics/payment service
|
Product parameter |
|
|
|
|
|
Model |
|
FD30 |
FD35 |
FD38 |
|
Rated lifting load |
kg |
3000 |
3500 |
3800 |
|
Load center distance |
mm |
500 |
||
|
Free lifting height |
mm |
160 |
||
|
overall length ( With fork/Without fork ) |
mm |
3752/2682 |
3763/2693 |
3963/2893 |
|
Width |
mm |
1225 |
||
|
Overhead guard height |
mm |
2090 |
||
|
Wheelbase |
mm |
1700 |
||
|
Minimum ground clearance |
mm |
135 |
||
|
Mast tilt angle (front/rear) |
% |
6°/12° |
||
|
Tire no. (before) |
|
28x9-15-14PR |
||
|
Tire no. (after) |
|
6.5-10-10PR |
||
|
Minimum turning radius (outer side) |
mm |
2400 |
2420 |
2710 |
|
Minimum right angle aisle width |
mm |
4260 |
4260 |
4720 |
|
Fork size |
mm |
1070X125X45 |
1070X125X50 |
1070x150x50 |
|
maximum working speed(Full-load/No-load ) |
km/h |
18/19 |
19/19 |
|
|
maximum lifting speed(Full-load/No-load ) |
mm/s |
440/480 |
330/370 |
340/380 |
|
maximum gradeability(Full-load/No-load ) |
% |
15/20 |
||
|
Forklift weight |
kg |
4250 |
4500 |
4800 |
|
Engine model |
|
XINCHAI/ISUZU/MITSUBISHI |
||
