New Tractor Farm Tractor, Garden Tractor, Lawn Tractor,Portable Harvester Newest Multifunctional Middle Size Garden Tractor
>Dual stage clutch
>Oil Immersed Disc Brake
>Power Steering
>Multi-valve hydraulic output
>PTO Rev.540/1000rpm
>Shuttle gearCreeper gear
New Tractor Farm Tractor, Garden Tractor, Lawn Tractor,Portable Harvester
Tractor Specifications and Features
Our classic and versatile wheeled tractor is designed to meet the demands of modern agricultural operations, combining reliable performance with a user-friendly design. Below is the detailed configuration and optional upgrades available for customization:
Powerful Solutions For Business Growth
Basic Configuration
Engine: Equipped with a powerful and efficient engine, delivering dependable performance.
Fuel Tank: Rear-mounted fuel tank for better balance and safety.
Instrument Panel: LCD instrument display for clear and accurate monitoring.
Hydraulic System: Strong lift and strong drop hydraulic system for efficient lifting operations.
Transmission: 8+2 side shift gearbox for smooth and precise gear shifting.
Counterweights: Front 8 and rear 2 counterweights, ensuring stability in various tasks.
Safety Features: Includes a protective safety frame for enhanced operator safety.
Hydraulic Multi-Way Valve: Three-link dual multi-way valve with floating function, offering versatility for attachments.
Attachments:
Quick connectors (2 sets) for easy and efficient operation.
Three-point hitch for attaching various implements.
Towing device for transport and field operations.
Floor Design: Features a pure flat floor for operator comfort and ease of use.
bY704
35-70 horsepower
Resistant and Durable Paddy king
characteristic
62 years of technological precipitation and durability.
Simple structure and convenient operation.
Post maintenance and repair, saving money and time.
in tractors with the same horsepower range,
the cost-effectiveness is higher.
More efficient homework
Adopting 8+2 gears, with reasonable speed matching and high work efhciency.
Compact structure, small overall size, strong power,
strong explosive power, and complete functionality,
Suitable for water and dry field operations, greenhouse planting, garden operations, and lawn management.
Standard equipped with a power level adjustment lifter,with a wide operating range.
Optional strong lifting and strong lowering single/dual3-way hydraulic output, supporting a variety of agricultural machinery.
| 404A-504A/Series Tractor>>> | |||||||
| (Main Technical Specifications): | |||||||
| Model | |-404A | -454A | -504A | ||||
| Type | 4×4Wheeled Type,4WD | ||||||
| (mm) Dimensions of Tractor |
Length | 3250 | 3350 | ||||
| Width | 1250 | 1300 | |||||
| Height | 1260 | 2000 | |||||
Tread |
Front Wheel | 960 | |||||
| Rear Wheel | 900-1020 | ||||||
| Wheel Base | 1725 | 1840 | |||||
| Min.Ground clearance | 210(the bottom of transfer case) | ||||||
| (kg)Min.operational Mass | 1440 | 1840 | |||||
Engine |
Model | KM490BT1 | M490T5 | KM4100BT | |||
| Type | Vertical,water cooled and 4-stroke | ||||||
| (kw) Rated Power |
29.4 | 33.1 | 36.8 | ||||
| (r/min) Rated Rev. |
2400 | 2300 | |||||
| Fuel | Diesel | ||||||
| Tire | Front Wheel | 7.00-12(6.00-12,6.00-16,5.00-12Optional) | |||||
| Rear Wheel | 13.6-16(9.50-20,9.50-24,9.50-16, 7.50-20,11.2-24Optional) |
||||||
| Clutch | dry-friction,single disc and constant engagement | ||||||
| Steering | Hydraulic Power Steering | ||||||
| Transmission Box | 2(4+1)×2((4+4)×2(4+1)×2×2) two shafts,(4+1)×2 composed ((4+4)×2or(4+1)×2×2 Optional) |
||||||
| Hitching Type | Post Positioned 3-point linkage Category I | ||||||
PTO |
(r/min) Type and Rev. |
540/760(540/1000/720) Rear mounted,semi-independent, 540/760(540/1000 or 720 Optional) |
|||||
Spline Size |
I35 Rectangle Spline with 6 teeth | ||||||
For additional versatility and comfort, the following upgrades are available upon request:
